Click2Angle

A mechanical torque wrench with smart technology, the Click2Angle provides an unprecedented combination of speed, angle precision, and value.

Click2Angle Logo

Part clicker. Part digital.
Completely innovative.

Introducing the first-ever hybrid torque wrench. The Click2Angle offers the best of both worlds – the speed of a mechanical clicker with the angle accuracy of an electronic torque wrench.

Experience the hybrid difference and never look back.

Brighter is better.

The Click2Angle takes high visibility to the next level. Its TFT display panel offers high-brightness and high-contrast modes. Plus, when measuring angle, the numbers change color and become bigger making it even easier to read.

Unique features that

make a big difference.

With a sleek design and innovative features, the Click2Angle makes your job faster and easier.

Low profile sealed 72-tooth ratchet head with 5-degree swing arc

Reversing lever

High-strength flex hinge with 15° stop

Heat treated steel tube

Impact resistant low-profile housing

Additional angle alert modes – buzzer, vibration, progressive green, yellow, red LEDs

High-visibility color TFT display

Angle mode button

Unit conversion button

Angle increment buttons

On/off and rezeroing button

Battery backup high-contrast SAE torque setting scale

Multifinger position auto locking collar

Comfortable anti-slip torque adjustment handle with load point

Rubber bumper end-cap

What makes the Click2Angle a hybrid?

Specifications

Quantum Tools Chart

Ready for a wide range of applications.

    • Extended range with increased torque capability meeting ASME B107.300 - 2021
    • 5 torque measurement modes in one micro-clicker torque wrench
    • Angle range 1-360°
    • Torque accuracy: ±3% CW and ±5% CCW, 20-100% of full scale
    • Angle accuracy: ±1% of reading, ±1° at angular velocity >10°/sec <180°/sec
    • 2-Year Limited Warranty and 90-day calibration guarantee
    • Includes blow molded storage box, 3 AAA alkaline batteries, and a calibration certificate
    • QC2A3300FA includes ¾″ adaptor
